博客：GPIO驱动改进版，字符设备驱动编写总结

嵌入式Linux驱动GPIO操作改进包括从驱动到测试程序

说明

这篇博客记录的是上一次编撰GPIO驱动的改进版本linux系统介绍red hat linux 下载。这儿改进了两个地方：

字符的驱动编撰小结字符设备驱动编撰步骤

这儿出现的代码是从前面的程序拷贝下来的嵌入式 linux驱动嵌入式 linux驱动。

字符设备驱动编撰步骤：

模块加载入口函数中：创建设备节点文件(为用户提供一个可操作的文件插口)硬件的初始化实现file_operations(文件插口的实现)操作寄存器的形式总结

	    u32 value = readl(led_dev->reg_virt_base);
	    value &=~(1<<0);
	    value |=1<reg_virt_base);
	    gpiol20_dat = gpiol20_cof+1;

		 writel(read(led_dev->reg_virt_base+4) |(1<reg_virt_base+4);

代码

#include
#include
#include
#include
#include
#include
#include
#include
#define GPIOL2_CON 0x11000000+0x0100
#define LEN 8
/*
用一个类来管理

*/
struct led_desc{
	unsigned int dev_major;
	struct class *cls;
	struct device *dev;
	void* reg_virt_base;
};
static struct led_desc *led_dev;
ssize_t chr_drv_read (struct file *filp, char __user *buffer, size_t count, loff_t *fpos)
{
	u32 value=0;
	int ret;
	printk("-------%s-------n",__FUNCTION__);

	value = readl(led_dev->reg_virt_base+4);
	value &=1<<0;
	ret = copy_to_user(buffer, &value, count);
	return 0 ;
}
ssize_t chr_drv_write (struct file *flip, const char __user *buffer, size_t count, loff_t *fpos)
{
	int ret;
	int value;
	static int num=0;
	printk("write:%d ",num++);
	ret = copy_from_user(&value, buffer, count);
	if(value == 1)
	{
	printk("vaule:%d n",value);
	writel(readl(led_dev->reg_virt_base+4) |(1<<0), 				led_dev->reg_virt_base+4);
	}
	else
	{
	printk("vaule:%d n",value);
	writel(readl(led_dev->reg_virt_base+4) & ~(1<<0), led_dev->reg_virt_base+4);
	}

	return 0;
}
int chr_drv_open (struct inode *inode, struct file *filp)
{
	printk("-------%s-------n",__FUNCTION__);
	return 0;
}
int chr_drv_release (struct inode *inode, struct file *filp)
{
	printk("-------%s-------n",__FUNCTION__);
	return 0;
}
static struct file_operations file_ops={

		.owner = THIS_MODULE,
		.open = chr_drv_open,
		.read = chr_drv_read,
		.write = chr_drv_write,
		.release = chr_drv_release,
};

static int __init chr_io_init(void)
{
	int ret;
	u32 value;
	printk("-----------%s--------n",__FUNCTION__);
	//GFP_KERNEL 如果内存不够用函数会一直阻塞（休眠）
	led_dev = kmalloc(sizeof(struct led_desc), GFP_KERNEL);
	if(led_dev == NULL)
	{
		//KERN_ERR 用于筛选调试信息
		printk(KERN_ERR "malloc error!n");
		return  -ENOMEM;
	}

	//动态分配设备节点
	led_dev->dev_major = register_chrdev(0 , "led",&file_ops);

	if(led_dev->dev_major < 0)
	{
		printk(KERN_ERR "register_chrdev error!n");
		ret  = -ENODEV;
		goto err_0;
	}
	led_dev->cls = class_create(THIS_MODULE, "led_cls");


	if(IS_ERR(led_dev->cls))//用宏做出错判断 在这里出错了 之前的都要释放
	{
		printk(KERN_ERR "class_create error!n");
		ret = PTR_ERR(led_dev->cls);//将指针出错的具体原因转换成出错码
		goto err_1;
	}
	led_dev->dev = device_create(led_dev->cls, NULL, MKDEV(led_dev->dev_major,0),
					NULL, "led%d",0);
	if(IS_ERR(led_dev->dev))
	{
		printk(KERN_ERR "device_create error!n");
		ret = PTR_ERR(led_dev->dev);
		goto err_2;
	}

	led_dev->reg_virt_base = ioremap(GPIOL2_CON, LEN);
	if(IS_ERR(led_dev->reg_virt_base))
	{
		printk(KERN_ERR "ioremap error!n");
		ret = -ENOMEM;
		goto err_3;
	}
	//规范的输入输出方式
	value = readl(led_dev->reg_virt_base);
	value &=~(1<<0);
	value |=1<<0;
	writel(value, led_dev->reg_virt_base);
	return 0;

	//梯形结构的错误处理
err_3:
	device_destroy(led_dev->cls , MKDEV(led_dev->dev_major,0));
err_2:
	class_destroy(led_dev->cls);

err_1:
	unregister_chrdev(led_dev->dev_major, "led0"); //先释放设备号 再释放内存空间
err_0:
	kfree(led_dev);//防止在发生错误的时候以前申请的内存得不到释放
	return ret;
}
static void __exit chr_io_exit(void)
{
	printk("-----------%s--------n",__FUNCTION__);
	iounmap(led_dev->reg_virt_base);
	unregister_chrdev(led_dev->dev_major, "led0");
	device_destroy(led_dev->cls, MKDEV(led_dev->dev_major,0)); //和创建相反
	class_destroy(led_dev->cls);

}
MODULE_LICENSE("GPL");
module_init(chr_io_init);
module_exit(chr_io_exit);
